Inform yourself about our extensive product range. Make a preselection and get a first overview. Our contact persons are available for your contact at any time. We will be pleased to advise you personally.
Case-Hardening Steel
Quality
16MnCr5 1.7131 | 16MnCrS5 1.7139 | 20MnCr5 1.7147 | 20MnCrS5 1.7149 |
Range
Profile | Dimension | DIN EN ISO 286 | Coil weight |
![]() | 5,00 - 15,00 mm | h9/h11 | 50 - 500 kgs |
Heat Treatment
+U untreated | +A annealed | +FP annealed |
Execution
+C cold drawn |
Not mentioned dimensions, profiles and special tolerances on demand. |
Quality
16MnCr5 1.7131 | 16MnCrS5 1.7139 | 20MnCr5 1.7147 | 20MnCrS5 1.7149 |
Range
Profile | Dimension | DIN EN ISO 286 | Length |
![]() | 4,00 - 80,00 mm | h6 - h11 | 100 - 6.000 mm |
![]() | 13,00 - 55,00 mm | h11 | 3.000 - 6.000 mm |
Heat Treatment
+U untreated | +A annealed | +FP annealed |
Execution
+C cold drawn | +SL ground | +SH peeled | defectomat/circograph control |
one/both sides chamfered |
Not mentioned dimensions, profiles and special tolerances on demand. |
Spring Steel
Quality
51CrV4 1.8159 |
Range
Profile | Dimension | DIN EN ISO 286 | Coil weight |
![]() | 8,00 - 46,00 mm | h11 | 300 - 1.800 kg |
Heat Treatment
+AC globular annealed |
Execution
+C cold drawn | phosphate-coated and drawn |
Not mentioned dimensions, profiles and special tolerances on demand. |
Quality
51CrV4 1.8159 |
Range
Profile | Dimension | DIN EN ISO 286 | Length |
![]() | 16,00 - 52,00 mm | h9/h11 | 500 - 8.000 mm |
![]() | 17,00 - 22,00 mm | h11 | 3.000 mm |
Heat Treatment
+AC globular annealed | +A soft annealed | +QT quenched and tempered |
Execution
+C cold drawn | +SH peeled | +SL ground | defectomat/circograph control |
one/both sides chamfered |
Not mentioned dimensions, profiles and special tolerances on demand. |
Corrosion-, Acid- and Heat-Resisting Spring Steel
Quality
1.4310 | 1.4568 | 1.4571 |
Range
Profile | Dimension | DIN EN ISO 286 | Coil weight |
rund | 0,20 - 19,00 mm | DIN EN 10270-3 | 50 / 100 / 200 / 500 kgs spools e.g. SH460, SH760 |
Execution
spring hard, coated | spring hard, polished |
Not mentioned dimensions, profiles and special tolerances on demand. |
Quality
1.4310 | 1.4571 |
Range
Profile | Dimension | DIN EN ISO 286 | Length |
1,00 - 12,00 mm | DIN EN 10270-3 | 3.000 mm |
Execution
spring hard, coated |
On request, we can deliver also fixed lengths. |
Not mentioned dimensions, profiles and special tolerances on demand. |
Tempering Steel
Quality
C60Pb 1.0602 | 42CrMoS4 1.7227 | 51CrV4 1.8159 |
Range
Profile | Dimension | DIN EN ISO 286 | Coil weight |
![]() | 5,00 - 20,00 mm | h9/h11 | 50 - 500 kgs |
Heat Treatment
+A annealed |
Execution
+C cold drawn |
Not mentioned dimensions, profiles and special tolerances on demand. |
Quality
C60Pb 1.0602 | 42CrMo4 1.7225 | 42CrMoS4 1.7227 | 30CrNiMo8 1.6580 | 34CrNiMo6 1.6582 | 51CrV4 1.8159 |
Range
Profile | Dimension | DIN EN ISO 286 | Length |
![]() | 5,00 - 80,00 mm | h6 - h11 | 3.000 - 6.000 mm |
![]() | 10,00 - 50,00 mm | h11 | 3.000 - 6.000 mm |
![]() | 13,00 - 55,00 mm | h11 | 3.000 - 6.000 mm |
Heat Treatment
+A annealed | +QT quenched and tempered |
Execution
+C cold drawn | +SL ground | +SH peeled | defectomat/circograph control |
one/both sides chamfered |
Not mentioned dimensions, profiles and special tolerances on demand. |
Roller Bearing Steel
Quality
100Cr6 1.3505 |
Range
Profile | Dimension | DIN EN ISO 286 | Coil weight |
![]() | 2,00 - 16,00 mm | h9/h11 | 50 - 500 kg |
Heat Treatment
+AC globular annealed |
Execution
+C cold drawn |
Not mentioned dimensions, profiles and special tolerances on demand. |
Quality
100Cr6 1.3505 |
Range
Profile | Dimension | DIN EN ISO 286 | Length |
![]() | 2,00 - 45,00 mm | h6 - h11 | 3.000 - 6.000 mm |
Heat Treatment
+AC globular annealed |
Execution
+C cold drawn | +SL ground | +SH peeled | defectomat/circograph control |
one/both sides chamfered |
Not mentioned dimensions, profiles and special tolerances on demand. |
Tool Steel
Quality
31CrV3 1.2208 | 115CrV3 1.2210 | 59CrV4 1.2242 | 61CrSiV5 1.2243 | 45SiCrV6 1.2249 | 45CrMoV7 1.2328 | 73MoV5.2 1.2381 | 90MnV8 1.2842 |
Range
Profile | Dimension | DIN EN ISO 286 | Coil weight |
![]() | 2,00 - 20,00 mm | h9/h11 | 100 - 500 kg |
![]() | 1,50 - 10,00 mm | h11 | 100 - 500 kg |
![]() | 5,00 - 10,00 mm | h11 | 100 - 500 kg |
Heat Treatment
+AC globular annealed | +A soft annealed |
Execution
+C cold drawn |
Not mentioned dimensions, profiles and special tolerances on demand. |
Quality
31CrV3 1.2208 | 115CrV3 1.2210 | 59CrV4 1.2242 | 61CrSiV5 1.2243 | 45SiCrV6 1.2249 | 45CrMoV7 1.2328 | 73MoV5.2 1.2381 | 90MnV8 1.2842 |
Range
Profile | Dimension | DIN EN ISO 286 | Length |
![]() | 2,00 - 35,00 mm | h6 - h11 | 3.000 - 4.000 mm |
![]() | 1,50 - 36,00 mm | h11 | 3.000 - 4.000 mm |
![]() | 5,00 - 20,00 mm | h11 | 3.000 - 4.000 mm |
![]() | 8,00 - 22,00 mm | h11 | 3.000 - 4.000 mm |
![]() | 14 x 9 - 26 x 13 mm | h11 | 3.000 - 4.000 mm |
Heat Treatment
+AC globular annealed | +A soft annealed |
Execution
+C cold drawn | +SL ground | +SH peeled | defectomat/circograph control |
one/both sides chamfered |
Not mentioned dimensions, profiles and special tolerances on demand. |
Corrosion-, Acid- and Heat-Resisting Steel/medical
Quality
1.4016 | 1.4034 | 1.4035 | 1.4104 | 1.4105 | 1.4301 | 1.4305 | 1.4307 |
1.4310 | 1.4362 | 1.4401 | 1.4404 | 1.4462 | 1.4541 | 1.4567 | 1.4571 |
1.4597 | 1.4828 | 1.4841 | 1.4845 |
Range
Profile | Dimension | DIN EN ISO 286 | Coil weight |
![]() | 0,50 - 18,00 mm | f8, h8, h9 | 50 / 100 / 200 / 500 / 1.000 kg spooled coils |
![]() | 1,00 - 8,00 mm | h11 | 50 / 100 kg |
![]() | 6,00 - 10,00 mm | h11 | 200 / 500 kg |
Heat Treatment
+C cold drawn (700 - 950 N/mm²) | +C +A cold drawn, annealed (max. 700 N/mm²) | +C +A +C cold drawn, annealed, cold drawn (700 - 800 N/mm²) | +C +A +LC cold drawn, annealed, low cold drawn (max. 750 N/mm²) |
Execution
+C cold drawn | bright | polished | electro polishing quality |
coated |
Not mentioned dimensions, profiles and special tolerances on demand. |
Quality
1.4016 | 1.4021/medical1 | 1.4034/medical1 | 1.4057 | 1.4104 | 1.4112/medical1 | 1.4122 | 1.4197/medical1 |
1.4301/medical1 | 1.4305/medical1 | 1.4307 | 1.4310 | 1.4362 | 1.4401 | 1.4404 | 1.4435 |
1.4441 ESU | 1.4462 | 1.4529 | 1.4541 | 1.4542/medical1 | 1.4548/medical1 | 1.4567 | 1.4571 |
1.4597 | 1.4878 | 1.4841 | 1.4845 |
1 acc. ASTM-F899 and ISO 7153-1 2 acc. ASTM-F138/F139 and ISO 5832-1 |
Range
Profile | Dimension | DIN EN ISO 286 | Length |
1,00 - 80,00 mm | h6 - h11 | 100 - 7.000 mm | |
4,00 - 60,00 mm | h11 | 3.000 - 6.000 mm | |
5,00 - 50,00 mm | h11 | 3.000 - 6.000 mm |
Heat
+A annealed | +QT quenched and tempered |
Execution
+C cold drawn | +SL ground | +SH peeled | defectomat/circograph control |
one/both sides chamfered |
Not mentioned dimensions, profiles, sheets and special tolerances on demand. |
Our delivery program as PDF-Download
